Platform Reduces 3D Printing Time and Waste, Increases Sustainability

Solution invented by University of Southern California engineers can reduce 35% of the material used in FDM additive manufacturing and also provide time savings.

Elizabeth Montalbano

April 21, 2021

4 Min Read
Adobe Stock

While 3D printing has provided a rapid platform for fabricating products in a way that is generally less time-consuming, it still has its drawbacks—one of the key ones being the amount of material waste it produces.

To solve this problem, researchers at the University of Southern California (USC) have created a low-cost printing method designed to reduce some of the major contributors of waste—supports that help maintain the integrity of printed objects that are removed after printing and discarded.

The team from USC’s Viterbi School of Engineering developed their solution for traditional 3D printing using the Fused Deposition Modeling (FDM) technique, which typically prints layer-by-layer, directly onto a static metal surface. It’s best suited now for use in the medical field but can expand to other industries.

The method instead uses a programmable, dynamically controlled surface made of moveable metal pins to replace the printed supports that would normally be used to hold the object while it prints--especially for objects of unusual shape.


A new dynamically-controlled base for Fused Deposition Modeling 3D printing (center) will reduce the need for printed supports (left) in an object, cutting waste and saving time.

In the USC researchers’ technique, the pins rise as the printer progressively builds the product, which in testing have demonstrated saving of about 35% of the materials that would typically be used to print objects in this way, said Yong Chen, professor of industrial and systems engineering at USC Viterbi’s Daniel J. Epstein Department of Industrial and Systems Engineering. He led the project with Ph.D. student Yang Xu.

Related:Researchers Devise Rapid 3D Printing Method for Human Organs

“For standard FDM printers, the materials cost is something like $50 per kilogram, but for bioprinting, it’s more like $50 per gram,” Chen said in a press statement. “So if we can save 30% on material that would have gone into printing these supports, that is a huge cost saving for 3D printing for biomedical purposes.”

In addition to cost savings and reducing environmental impact with the solution, researchers said the new method also can save medical professionals time in the fabrication of a part, which can be crucial in a medical setting.

“When you’re 3D-printing complex shapes, half of the time you are building the parts that you need, the other half of the time you’re building the supports,” Chen said in a press statement. “So with this system, we’re not building the supports. Therefore, in terms of printing time, we have a savings of about 40%.”

A New Means of Support

Specifically, the prototype works by running each of its supports from a single motor that moves a platform. The platform then raises groups of metal pins at the same time to support the part as it prints.

Related:Is 3D Printing Right for Your Medical Device Project?

How those pins are used is based on the product design and program software that uses it to tell the user where they need to add a series of metal tubes into the base of the platform. The position of these tubes then determines which pins would raise to defined heights to best support the product, minimizing waste. At the end of the process, the pins can be removed from the product without damaging it.

This design is different than similar prototypes developed in the past to fabricate products in this way, which relied on individual motors to raise each of the mechanical supports, Chen said. This resulted in highly energy-intensive products that also were much more expensive to purchase.

“So if you had 100 moving pins and the cost of every motor is around $10, the whole thing is $1,000, in addition to 25 control boards to control 100 different motors,” he explained. “The whole thing would cost well over $10,000.”

Researchers published a paper on their work in the journal Additive Manufacturing.

The team said its solution eventually can be scaled for use to fabricate parts beyond the medical field to the automotive, aerospace, and yacht industries.

To further their research and commercially distribute the platform, the research team—which also includes Ziqi Wang, previously a visiting student at USC from EPFL Switzerland, and Siyu Gong from USC--has applied for a patent for their technology.
