Converting Machined Parts to Die Castings

Page 1 / 3 Next >
View Comments: Newest First|Oldest First|Threaded View
Greg M. Jung
User Rank
Die Casting
Greg M. Jung   9/15/2012 3:36:50 PM
I agree that converting machined parts to die casting usually makes sense.  Because die casting tools can be expensive, it is important to first do a pay-back analysis and see if the volumes justify this change over.

In many cases we use both processes during the life of the product.  When the initial design is likely to change and we need to enter the market quickly, we may start with a machined part.  Then, as the design becomes stable and production volumes increase, we plan for a smooth cut-over to die cast tooling.


Dave Palmer
User Rank
Comparing processes
Dave Palmer   8/6/2012 12:31:33 PM
In most cases, casting a part versus machining it from bar stock is a no-brainer.  In my career, I've only come across one part that made more sense as a screw-machined part than as a die casting.  In that case, the geometry of the part made it extremely easy to screw machine.  Also, screw machining allowed the part to be made out of a much stronger wrought alloy.  It wound up being an 80% cost savings (from $4 to about 80¢), along with a more than 50% increase in strength.

But this is far from the norm, and as this article shows, casting is almost always much cheaper.  A more interesting comparison would be between die casting and powder metallurgy.  It would also be worthwhile to compare different casting processes (die casting, semi-solid processing, permanent mold, investment casting, lost foam, etc.).  In addition to cost, these processes also vary in terms of the mechanical properties and dimensional accuracy that can be achieved.
