A DIY project to help with your DIY projects? This edition of Gadget Freak is going meta with a CNC laser engraver made by Amy Kippen and her team of fellow students at Colorado State University.
The CNC laser engraver consists of a user-controlled laser mounted to the Y axis and an engraving plate mounted to the X axis. Motion of the laser and engraving plate are controlled using G-code, which allows the laser to engrave two dimensional designs or images into wood.
A user can input G-code through an SD card on the back of the LCD display. Using the push-button/dial to control the LCD screen, the user selects the correct G-code. The LCD also provides users with visualization and control over the laser casing temperature via alteration of fan speeds. The X and Y axes are each controlled by a stepper motor, and proximity switches are used to limit the motion of each axis past structure walls.
The engraver is also equipped with a safety feature that turns off the laser when the door is open and a program is running. A green LED is lit while the engraver is running. If the door is opened a limit switch inside the door is disengaged and a signal is sent to turn off the green LED and turn on the safety feature, which includes a red LED and an alert buzzer. Disengaging the limit switch also triggers a relay that turns off the laser. Once the door is closed the laser resumes engraving.
Click the image below for a slideshow of the build instructions.
And click here to download the full build instructions including schematics, diagrams, and code.
Do you have a cool, original, homemade gadget you'd like to share with the world? Give us the details at DesignNews.com/GF, and you may receive $500 and automatic entry into our $6000 Gadget Freak of the Year contest!
2W 445nm M140 Blue Diode in Copper Module W/Leads & Three Element Glass Lens
voltage and current regulator display
DC-DC Voltage Buck Converter Volt Regulator Display
Aluminum mount and heat sink for 12mm modules
13 ft of 1 x 1-inch alumium tube
2 ft 2 x 2-inch aluminum angle
Hex machine screw nut, 8-32
Truss combo head machine screw, 8-32 x 1-½”
HDE laser eye protection safety glasses for green and blue lasers
Do you have a cool, original, homemade gadget collecting dust in your garage? Give us the details at DesignNews.com/GF, and you may receive $500 and automatic entry into our $6000 Gadget Freak of the Year contest!
[All images courtesy Amy Kippen]
